Peripheral

• Accessory Port

• Ronin Series Accessories (RSA)/NATO Ports
  1/4"-20 Mounting Hole
  Cold Shoe
  Camera Control Port (USB-C)
  Multifunctional Port (USB-C)

• Battery

• Model: BHX715-2150-15.48
  Type: LiPo 4S
  Capacity: 2150 mAh
  Energy: 33.29 Wh
  Voltage: 11.2 V to 17.8 V
  USB Input: 5 V/3 A, 9 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/3 A
  Max Standby Time: Approx. 14 hours*
  Charging Time: Approx. 1 hour**
  Suggested Charging Temperature: 5° to 40° C (41° to 104° F)^{* The 14-hour standby time is achieved with the DJI RS BG33 Battery Grip. The DJI RS BG33 Battery Grip is not available for purchase in India. This data is measured with the gimbal balanced in a level and stationary state. ‌When the gimbal is in motion, the operating time will be reduced.
  ** Measured at an ambient temperature of 25° C (77° F) using a 65W charger supporting PD protocol to fully charge the DJI RS BG33 Battery Grip. The DJI RS BG33 Battery Grip is not available for purchase in India.}

• Connections

• Bluetooth 5.0
  USB-C Charging Port

• Ronin App Requirements

• iOS 14.0 or above
  Android 9.0 or above

• Languages Supported by the Touchscreen

• English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai

Working Performance

• Tested Payload

• 3.0 kg (6.6 lbs)

• Maximum Controlled Rotation Speed

• Pan: 360°/s
  Tilt: 360°/s
  Roll: 360°/s

• Mechanical Range

• Pan Axis: 360° continuous rotation
  Roll Axis: -95° to +240°
  Tilt Axis: -112° to +214°

• Axis Lock

• Auto

• Vertical Shooting

• Supported

Mechanical & Electrical Properties

• Operating Frequency

• 2.4000-2.4835 GHz

• Bluetooth Transmitter Power

• < 8 dBm

• Operating Temperature

• -20° to 45° C (-4° to 113° F)

• Weight

• Gimbal: Approx. 1193 g (2.63 lbs) (including the Upper and Lower Quick-Release Plates and screws)
  Grip: Approx. 274 g (0.6 lbs)
  Quick-Open Tripod: Approx. 149 g (0.3 lbs)
  Upper and Lower Quick-Release Plates: Approx. 93 g (0.21 lbs) (including screws)

• Dimensions

• Folded: 247.4×115.7×258.7 mm (L×W×H, excluding camera, grip, and the Quick-Open Tripod)
  Unfolded: 223.2×192.2×418.8 mm (L×W×H, including grip, excluding camera and the Quick-Open Tripod)

Accessories

• DJI RS Enhanced Intelligent Tracking Module

• Weight: Approx. 19 g (0.04 lbs)
  Dimensions: 35.9×17.5×38.5 mm (L×W×H)
  Tracking Distance: 0.5-10 m
  Operating Environment: Illuminance > 20 lux
  Trigger Methods: Gimbal trigger, gesture, gimbal touchscreen
  Gesture Functions: Start/stop of tracking, start/stop of recording, framing adjustment
  Power Consumption: Approx. 1 W
  Operating Temperature: -10° to 45° C (14° to 113° F)
  Mounting Method: Magnetic attachment

• Electronic Briefcase Handle

• Weight: Approx. 230 g (0.51 lbs)
  Dimensions: 60×197.5×79.5 mm (L×W×H)
  Standby Power Consumption: Approx. 0.2 W
  Operating Temperature: -20° to 45° C (-4° to 113° F)
